- Place of Origin:CN;GUA
- Brand Name:OEM
- Model Number:Trail Camera with 3G
- Model Type:Trail camera with 3G
- Image resolution:5-12MP
- IR night vision:54pcs 940nm IR Leds
- PIR:Optional 110 or 62 degree
- Multi-photo shot:Up to 5 pics per trigger
- Screen:2.0'' color display
- Authentication/ Certificates:CE, FCC, RoHs
- Other functions:Camera ID,Time Lapse; Auto photographing
- Support bands:900/2100 & 850/1900 MHz (3G network)
- Product series:Wholesale wireless 3g trail camera
Model No. | Functions | Remarks |
2.6C | Basic model, 5MP COMS, 1080P, 2.0' color screen, | available now |
2.6CM | With GPRS/MMS/SMTP, cell phone access option | available now |
2.6CW | With Wi-Fi option, check download images or change setting via APP | customize only |
2.8C | Basic model, 1.3MP CMOS, 720P, B/W screen, 26pcs LEDs | available now |
2.8P | Basic model, 1.3MP CMOS, 720P, B/W screen, 40pcs LEDs | available now |
3.0C | Basic model, 5MP COMS, 1080P, 2.0' color screen, 56pcs LEDs Lens angle: 100 degree, PIR angle: 100 degree | available now |
3.0CG | With 3G option, send photos to server, remote management | available now |
Unparalleled Advantages:
1. 0.4 secs trigger time/ speed;
2. 12MP crystal clear photo;
3. 1080P @ 30fps video recording;
4. 100 degree PIR;
5. 90 degree FOV of lens;
6. 54 IR LEDs for 20 meters/ 65 feet night vision;
7. 5 photos multi-shot within 1 second;
8. Unbeatable unit price compare to similar models in the market
9. Supports two types of 3G network frequency: 900/2100 & 850/1900 MHz
Image Sensor | 5 Mega Pixels Color CMOS | |
Effective Pixels | 2560x1920 | |
Day/Night Mode | Yes | |
IR range | 20m | |
IR Setting | Top: 25 LEDs, Foot: 31LEDs | |
Memory | SD Card (8MB – 32 GB) | |
Operating keys | 10 | |
Lens (Wide lens model) | F=3.0; FOV=100°; Auto IR-Cut-Remove (at night) | |
Lens (Regular lens model) | F=3.0; FOV=52°; Auto IR-Cut-Remove (at night) | |
LCD Screen | 2” TFT, RGB, 262k | |
PIR Sensitivity | 3 sensitive levels: High / Normal / Low | |
PIR distance | 12m – 15m | |
PIR Angle | 110° | |
Picture size | 5MP/8MP/12MP =2560x1920/3264x2448/4000x3000 | |
Picture Format | JPEG | |
Video resolution | 1080P (1920x1080): 30FPS, 720P (1280x720), 640x480 | |
Video Format | AVI | |
Video Length | 5-60sec. programmable | |
Shooting Numbers | 1-7 | |
Trigger Time | 0.35~0.45s | |
Trigger Interval | 2s-5s | |
Camera + Video | Yes | |
Playback Zoom in | 2x, 3x, 4x | |
Device Serial No. | Yes | |
Time Lapse | Yes | |
Beep Sound | ON/OFF | |
Trigger Logs (PIR Log Recording) | Yes (Unique Feature) | |
Operation Power | Battery: 12V; DC: 12V | |
BatteryType | 8AA | |
External DC | 12V | |
Stand-by Current | 0.173mA | |
Stand-by Time | 4~6 months (4×AA~8×AA) | |
Auto Power Off | auto switch to mode “ON” in 60s without any operations | |
Power Consumption | IR LEDs Off | Photo: 120mA; Video: 110mA |
IR LEDs On | Photo: Max.Range:1050mA Balanced:1280mA Min.Blur:1560mA Video: 910mA | |
Low battery Alert | 8.8V (8.8V: alert; 8.6V: power off) | |
Interface | TV out/USB/SD Card/DC Port | |
Mounting | Strap; Tripod | |
Storage temperature | -30 °C to 70°C | |
Operation Humidity | 5%-90% | |
Waterproof spec | IP54 | |
Dimensions | 131.42 x98.72 x77.44mm | |
Weight | 404g | |
Certification | CE FCC RoHs | |
Why choose us?
Willfine Century co., ltd is a REAL Manufacturer, support OEM, ODM.
- We offer the first-hand prices;
- With 15 years experiences of manufacturing and exporting;
- With professional R&D team for new generation products continuously;
- Offer the best services for clients, including model choosing assistance, technical supports, payment and shiping methods advices, and customized products and packing services.
